Extender HDMI on Cat.6/6a/7 twisted pair, up to 60m, FullHD 3D, black
Technical data
Type | Adapter |
Colour | Black |
Dimensions | 66 x 56 x 22 mm |
Other features | - Transmission range: 60m - Resolution: 480i @ 60Hz, 480p @ 60Hz, 576i @ 50Hz, 576p @ 50Hz, 720p @ 50 / 60Hz, 1080i @ 50 / 60Hz, 1080p @ 50 / 60Hz. - Bandwidth: 10.2Gbps - Power supply: 2x DC5V1A |
Accessories included | - HDMI transmitter extender - HDMI receiver extender - Power supply DC5V1A x 2 - User instructions |
Usage | Computer |
Connectors #1 | RJ45 Female |
Connectors #2 | RJ45 Female |
Standard | HDMI High Speed with Ethernet |
Designation | CE+WEEE |
Description
HDMI Extender on Cat.6/6a/7 twisted pair, up to 60m, FullHD 3D
- A simple way to extend the HDMI 1.3b signal with Cat6 / Cat7 cabling
- Allows you to place the monitor in a convenient location
- Provides up to 60m of A / V signal transmission with up to 1080p resolution using a single RJ45 UTP Cat6 / Cat7 cable - Use only fully-featured copper cables for reputable brands such as Intellinet;
- Compact size
- Supports 8-bit color depth (Deep color) per channel (24-bit for all channels)
- Supports stereo PCM sound
- Automatic adjustment allows you to adjust the settings according to different cable lengths from 1 to 60m, for the best possible view.
- Supports 3D format
66 x 56 x 22 mm
- HDMI transmitter extender
- HDMI receiver extender
- Power supply DC5V1A x 2
- User instructions
- Transmission range: 60m
- Resolution: 480i @ 60Hz, 480p @ 60Hz, 576i @ 50Hz, 576p @ 50Hz, 720p @ 50 / 60Hz, 1080i @ 50 / 60Hz, 1080p @ 50 / 60Hz.
- Bandwidth: 10.2Gbps
- Power supply: 2x DC5V1A
