Teltonika Gateway LTE TRB255 Cat M1/NB 2G Ethernet

<< Previous Next >>

Availability:

Out of stock

Price: €254.23 254.23

quantity pcs

add to wish list

Brand: TELTONIKA

Product code/SKU: 978158

Technical data

Type	GSM 3G/4G
Colour	Aluminium
Dimensions	83 x 25 x 74 mm
Weight	165 kilogram
Other features	Network support: 4G/LTE (Cat M1), NB-IoT, 2G CPU: Qualcomm, MIPS 24Kc, 650 MHz Memory: Memory 16 MB Flash, 64 MB RAM Antenna connectors: 1 x SMA (cellular), 1 x SMA (GNSS) GNSS: GPS, GLONASS, BeiDou, Galileo, QZSS Status LED: 3 x network type, 3 x signal strength, 2 x Ethernet, power Housing: Aluminum with DIN mounting option Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, DHCP
Accessories included	TRB255 9W power supply Cellular antenna, rotatable, 1 piece (SMA male) GNSS antenna 1x (self-adhesive, SMA male, 3m cable) 16 pin connector (terminal block) Assembly key Ethernet cable (1.5 m) Quick start guide RMS leaflet
Model	TRB255
I/O ports	1 x RS-485
Power supply	16 pin terminal, 9-30 VDC
Security	Authentication: Pre-shared key, digital certificates, X.509 certificates Firewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) VLAN (planned): Tag based VLAN separation Mobile quota control: Custom data limits for both SIM cards WEB filter (planned): Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter
Card reader	None
Data transmission	LTE
GSM network	1900 MHz
LTE network	1900 MHz
SIM card	Mini
Antenna	Detachable external
Environment requirements	Operating temperature range: -40 °C to 75 °C Humidity range: 10-90% non-condensing
Standards	802.3u
Number of antennas	Two connectors
Management, monitoring, configuration	Mobile features: Multiple PDN, Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits Monitoring and management: WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS, Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx NTP: NTP Server, NTP Client, Sync with: External NTP server, GNSS, Mobile operator GNSS: NMEA forwarding, AVL, Geofencing Modbus: TCP slave, TCP master, RTU master, RTU gateway, Modbus over MQTT Serial: Console, Over IP, Modem, NTRIP, Modbus Administration: Multi user, Configuration profiles, Diagnostics, logs, Configuration backup
Software	RutOS
Aero2 support	No
Designation	CE+WEEE
