Lanberg Switch 16X 100MB POE+/2X Combo Unmanaged Rack 19" Gigabit Ethernet 250W

<< Previous Next >>
Availability: Low Stock
Delivery: 15-05-2024
Price: €297.20 297.20
quantity pcs
add to wish list
Brand: LANBERG
Product code/SKU: 729860

Technical data

Dimensions 208 x 320 x 45 mm
Weight 1.9 kilogram
Other features Protection class: IP20 Cooling: Vents, Passive Operation signalling: LED Data communication height: 1 U Number of screws required: 4
Application Medium and large companies
Power consumption 250 Watt
Network architecture GigabitEthernet
Fan No
Power supply Mains (230V) PoE: PoE, PoE+ Supported PoE standards: 802.3af, 802.3at Maximum power per port: 30 W Total PoE budget: 250 W
Chassis type Rack
Switch class Unmanaged
Number of 10/100/1000 Mbps ports 2
Number of SFP+ ports None
Throughput 3.6 GB/s
Forwarding rate 1000 MB/s
MAC address table size 16000
Number of 10/100 Mbps ports 16
Number of 10Gb ports None
Number of PoE ports (PoE & PoE+) 16
Number of PoE+ ports None
Number of COMBO ports 2
Number of SFP ports None
Number of QSFP+ ports None
Console port No
Supported protocols and standards IEEE 802.3af PoE IEEE 802.3at PoE+ IEEE 802.3i 10Base-T IEEE 802.3u 100Base-TX IEEE 802.3x (Flow-Control)
10/100/1000/2500 Mbps ports None

Description

The switch is fitted with a total of 18 RJ-45 ports, including 16 PoE+ (Fast Ethernet) and 2 Uplink (Combo Gigabit) ports. The well-thought-out design and attention to details and quality of components enable the user to achieve up to 150 W of real power for the end-devices, which translates into the simultaneous connection of:

  • 16 IEEE 802.3af devices (max. 15W per port) or,
  • 8 IEEE 802.3at devices (max. 30W per port),



The 2 remaining (Uplink) ports are dedicated to transferring data traffic between 16 PoE+ ports and external devices. In the case of surveillance/control systems, this is particularly useful as it allows the user to simultaneously play the recording(s) from the IP cameras on the NVR and share it further, e.g., in the local network or on the Internet.
