Hikvision KH6 Series IP-Based Indoor Station DS-KH6320-WTE1

KH6 Series IP-Based Indoor Station
New UI V2.0: User friendly design
7-inch colorful touch screen with resolution 1024 × 600
Standard PoE
Stores messages and capture pictures in the TF card
Remote unlocking via the client software or the mobile client
Views live videos of door stations and linked cameras

System Parameters
Operating System
Embedded Linux operation system
ROM
32 MB
RAM
128 MB
CPU
Embedded processor
Display Parameters
Screen Size
7-inch colorful TFT screen
Operation Method
Capacitive touch screen
Type
Colorful TFT screen
Resolution
1024 × 600
Video Parameters
Lens
/
Resolution
/
FOV
/
WDR
/
Video Compression Standard
DS-KH6320-WTE1
Focal Length
/
Audio Parameters
Audio Compression Standard
G.711 U
Audio Input
Built-in omnidirectional microphone
Audio Output
Built-in loudspeaker
Audio Compression Bitrate
64 Kbps
Audio Quality
Noise suppression and echo cancellation
Volume Adjustment
Adjustable
Capacity
Notice Capacity
200
Linked Network Camera Capacity
16
Linked Indoor Extensions Capacity
5
Linked Doorphone Capacity
8
Network Parameters
Communication Protocol
TCP/IP, SIP, RTSP
Wired Network
10/100 Mbps self-adaptive
Wi-Fi Standard
Wi-Fi 802.11 b/g/n
Bluetooth Version
/
3G/4G Standard
/
Zigbee
/
Device Interfaces
Alarm Input
8-ch alarm inputs
Network Interface
1 RJ-45 10/100 Mbps self-adaptive
TAMPER
/
RS-485
1
USB
/
TF Card
Max to 32 G, SD 2.0 or lower version
Alarm Output
2
Power Interface
1
General
Button
0
Installation
Surface mounting
Indicator
0
With package: 683 g

Without package: 355 g

Protective Level
/
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10% to 90%
Dimensions
200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6")
Battery
/
Application Environment
Indoor
Power Consumption
≤ 6 W
Language
English, French, Portuguese (Brazil), Spanish, Russian, German, Italian, polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Greek
Face Recognition Terminal/General
Power Supply Method
IEEE802.3af, standard PoE

12 VDC/1 A
