Teltonika Router LTE RUT956 Cat4 2G GNSS WiFi

<< Previous Next >>
Availability: Available
Delivery: 04-12-2024
Price: €450.07 450.07
quantity pcs
add to wish list
Product code/SKU: 978134

Technical data

Type GSM 3G/4G
Colour Black
Dimensions 110 x 50 x 100 mm
Weight 295 gram
Other features Network support: 4G/LTE (Cat 4), 3G, 2G CPU: Mediatek MIPS 24Kc 580MHz Memory: 16 MB Flash, 128 MB RAM LED: 2-color network type indication, 5x signal strength, 4x Ethernet, power supply 10 pin connector: 1 x isolated input, 1 x digital input (dry), 1 x analog input, 1 x isolated open collector output (requires external voltage), 1 x relay output
Accessories included RUT956 router 9W power supply 2 x LTE antenna (magnetic mount, SMA male, 3 m cable) 2 x WiFi antenna (magnetic mount, RP-SMA male, 1.5 m cable) GNSS antenna (adhesive, SMA male, 3 m cable) RS485 block connector I/O block connector Ethernet cable (1.5 m) SIM Adapter kit RMS leaflet Quick Start Guide
Model RUT956
I/O ports 1 x RS-485
Power supply 4pin connector, 9-30 VDC
Security Authentication: Pre-shared key, digital certificates, X.509 certificates Firewall: Pre-configured firewall rules can be enabled via web-ui, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention ( SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) VLAN: Port and tag based VLAN separation Mobile quota control: Set up custom data limits for both SIM cards WEB filter: Blacklist for blocking out unwanted websites, whitelist for specifying allowed sites only Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter Secure Boot: Cryptographic integrity check of the each system boot process (available on device with special order code RUT955T073B0). WiFi security: WPA2-Enterprise - PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK; AES-CCMP, TKIP, Auto Cipher modes, client separation
Card reader None
Data transmission LTE
GSM network 900 MHz
UMTS network 2100 MHz
LTE network 1800 MHz
SIM card Mini
Antenna Detachable external
Environment requirements Operating temperature: -40°C to 75°C Operating humidity: 10% to 90% non-condensing
Operating frequency 2,4 GHz
Standards 802.3
Number of antennas Five connectors
Management, monitoring, configuration Cellular functions: Band lock, SIM switch, Operator black/white list, Data/SMS limits Network: Failover (Network backup), VLAN, QoS, Load Balancin Monitoring and management: WEB UI, CLI, SSH, CALL, SMS, TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx NTP: NTP Server, NTP Client, Sync with: External NTP server, GNSS, Mobile operator GNSS: NMEA forwarding, AVL, Geofencing Modbus: TCP slave, TCP master, RTU master, RTU gateway, Modbus over MQTT Serial: Console, Over IP, Modem, NTRIP, Modbus
Software RutOS (OpenWrt based Linux OS)
Aero2 support No

Description

110 x 50 x 100 mm
