LG USB One Quick Share SC-00DA.AEUQ
Technical data
Dimensions | 63.8 × 63.8 × 13.5 mm / USB cable (85.5 mm) |
Weight | 46 gram |
Other features | User switching: Yes Split view: Yes (max. 4 screens) Administrator mode: Yes Signage control: Yes Audio: Windows only Embedded operating system: Linux CPU: Quad-core CortexTM-A7 Internal memory: eMMC (4 GB) , DDR3 (512 MB) Wi-Fi: IEEE 802.11 a/b/g/n/ac (max. 30 m available) Video: H.264 Connectivity: USB 2.0 Type A (1) Operating temperature / humidity: 0 deg C to 40 deg C / 0% to 85% Operating Systems Support: Windows 7 SP1 / 8 / 8.1 / 10 64-bit macOS 10.11 / 10.12 / 10.13 / 10.14 / 10.15 64-bit CPU: Intel Sandy Bridge i3 (or later) Skylake i3 / i5 / i6 (or later) AMD Ryzen 1st generation (or later) |
Power consumption | 2.5 Watt |
Operating system | Linux |
Warning | CE+WEEE |
Description
USB One: Quick Share
Simple and efficient connection
LG One:Quick Share is a wireless screen sharing solution available with LG webOS Signage devices. It is a USB to computer data transfer module (SC-00DA) and application. With One:Quick Share, users can easily share their computer screen to the LG monitor and can manage the basic functions of the LG Signage device.
Easy pairing
USB attachments can be connected to LG Signage displays to automatically pair the devices, which can then be easily disconnected. Once connected, the devices are ready for pairing.
Plug and Play
Easily share your computer screen on the LG Signage screen by plugging the USB Attachment into your PC and pairing the devices.
One-click wireless screen sharing
With the press of a button on the USB Set Top Box, you can share your PC screen, switch to another screen or show up to 4 screens on your Signage device at once.
Built-in Wi-Fi
With LG Signage's SoftAP feature, the USB Appliance and Signage screens can be easily connected without the need for an additional transmitter.
Remote-free settings
Use the One:Quick Share PC app to adjust default Signage screen settings (volume, picture mode, auto brightness adjustment, etc.) without a remote control, and edit schedules and notes or Office Meeting presentation settings.
Screen Manager
Shared screens on the Signage screen can be managed by a meeting organiser with administrator privileges. He or she can rearrange shared screens, disable selected screens and choose from a number of linked screens.
63.8 × 63.8 × 13.5 mm / USB cable (85.5 mm)
- User switching: Yes
- Split view: Yes (max. 4 screens)
- Administrator mode: Yes
- Signage control: Yes
- Audio: Windows only
- Embedded operating system: Linux
- CPU: Quad-core CortexTM-A7
- Internal memory: eMMC (4 GB) , DDR3 (512 MB)
- Wi-Fi: IEEE 802.11 a/b/g/n/ac (max. 30 m available)
- Video: H.264
- Connectivity: USB 2.0 Type A (1)
- Operating temperature / humidity: 0 deg C to 40 deg C / 0% to 85%
Operating Systems Support:
- Windows 7 SP1 / 8 / 8.1 / 10 64-bit
- macOS 10.11 / 10.12 / 10.13 / 10.14 / 10.15 64-bit
CPU:
- Intel Sandy Bridge i3 (or later)
- Skylake i3 / i5 / i6 (or later)
- AMD Ryzen 1st generation (or later)
