Benq Projector MH733 DLP 1080p 4000ANSI/16000:1/HDMI
Technical data
Dimensions | 296 x 120 x 221 mm |
Weight | 2.5 kilogram |
Other features | Working temperature: 0 ~ 40°C Storage temperature: -20 ~ 60°C Humidity: 10 ~ 90% RH (non-condensing) Keystone correction in two planes Automatic tarp correction Corner adjustment (Corner Fit) USB reader LAN Control AMX/PJ Link/Crestron/Extron IPL Compatibility MDA LAN Display compatibility Split the screen into 4 Simultaneous work using the QCast application |
Accessories included | Power cable Remote control AAA x2 batteries VGA cable Warranty Card Quick start guide User's manual on CD Lens cover |
Wireless communication | Optional |
Noise | 33 Decibel |
Aspect ratio | 16:9 |
Resolution | 1920 x 1080 (FHD 1080) |
Brightness | 4000 ANSI Lumen |
Static contrast | 16 000:1 |
Frequency, horizontal (min) | 15 kHz |
Frequency, horizontal (max) | 102 kHz |
Frequency, vertical (min) | 23 Hz |
Frequency, vertical (max) | 120 Hz |
Number of colours | 1,07 mld |
I/O connectors | 1 x Audio in |
Power consumption | 320 Watt |
Display technology | DLP |
Zoom | 1,3x |
Automatic focus adjustment | No |
Minimum image diagonal | 30" |
Maximum image diagonal | 300 Millimetre |
Light life-time | 4000 Hour |
Audio | Yes |
Projection ratio (min) | 1,15:1 |
Projection ratio (max) | 1,50:1 |
Light life-time (ECO mode) | 8000 Hour |
Compatibility with computer standards | 480i 480p 576i 576p 720p 1080i 1080p |
Compatibility with video standards | NTSC PAL SECAM |
Description
Business Full HD projector for conference rooms
- 4000 ANSI Lumens high brightness
- Full HD 1080p resolution
- USB reader for presentations without a computer
- Simple presentation over the local network thanks to the QCast app
- Compatible with AMX / Crestron / Extron control systems
Vivid and sharp colors in brightly lit rooms
The 4000lm high brightness of the MH733 allows speakers and participants to enjoy presentations in comfortably lit medium-sized meeting rooms, providing endless opportunities for discussion, collaboration, note-taking and interaction, leading to effective meetings. High brightness guarantees professional image quality for business users, meeting strict corporate requirements.
Full HD resolution ensures a clear image and greater content density
Featuring native Full HD (1920 x 1080) resolution in 16: 9 widescreen format, BenQ business projectors display subtle details, offer razor-sharp and clear images and greatly improved image quality for professional presentations.
USB reader for presentations without a computer
With support for multiple file formats such as JPEG, PDF, Microsoft Word, Excel and PowerPoint, the MH733's USB Type A connector allows speakers to easily display photos or documents directly from media without using a laptop.
Easy presentation over the local network thanks to the QCast application
After installing the MH733 on a LAN and pairing it with the QCast App, you can easily deliver presentations from computers or smart devices. The QCast application allows users to directly display photos and various files such as PowerPoint, Word, Excel and PDF on the large screen from computers or smart devices. Besides, the QCast App offers additional useful features to improve the overall efficiency and convenience of your business meetings.
Easy wireless presentations with the optional WDRT8192 USB card
After connecting the WDRT8192 wireless USB card, the MH733 allows convenient wireless display from a computer or mobile device via the QCast app.
Present wirelessly from any computer or mobile devices
Offering users multiple wireless projection options, QCast App can mirror the contents of the computer or extend the screen to share information while retaining other data. The MH733 allows you to wirelessly display static photos or documents including PowerPoint, Word, Excel and PDF files. On devices with Android 5.0 and above. Users can display the content of mobile devices on the big screen.
Split-screen display and effective meeting organization
The MH733 allows content from up to four different computers or smart devices to be displayed via the QCast App, allowing even more ideas to be effectively shared.
Internet connection via QCast application
The QCast App offers MH733 users flexible internet connectivity via an external internet connection. Speakers can browse the Internet when needed to research and share information.
Handy remote control function
The QCast App also offers a convenient remote control function with easy-to-use buttons to control the projector when it is ceiling-mounted or when the remote control is not available.
Advanced image calibration for perfect image alignment
The MH733 is equipped with a two-dimensional keystone range of 30 degrees horizontally and 20 degrees on the vertical axes to counteract the trapezoid effect when the projector needs to be installed off-center. Installers can use the corner fit feature to independently adjust each angle to achieve perfectly aligned image geometry.
Extensive LAN control functions
The MH733 is compatible with many leading projector LAN control systems, including Crestron, AMX, PJLink and Extron IP Link, making it easy to integrate into your corporate infrastructure. In addition to direct 1-to-1 projector control via a web browser, BenQ's Multiple Display Administrator (MDA) software offers powerful multi-projector centralized management functions, including automatic opening and closing in public spaces, remote on and off, and scheduling for offices and businesses.
Centralized control of multiple projectors with BenQ MDA software
BenQ Multiple Display Administrator (MDA) software provides efficient centralized management of multiple projectors, including automated opening and closing procedures for public places, remotely controlled power on and off, and device scheduling for institutions and corporations.
Direct control via a web browser
The MH733 allows IT managers to conveniently control any projector via a web browser without having to physically visit the conference room, saving time and effort.
LampSave Mode
With less lamp replacement and maintenance, the overall cost of ownership is lower. LampSave mode dynamically adjusts lamp power to the content displayed, extending lamp life by up to 50% compared to normal mode.
Long-lasting Image Perfection with DLP Technology
The 2015 Oscar statuette (Oscar statuette) digital image processing technology, Digital Light Processing (DLP), is the leading projection technology used in 90% of the world's digital cinemas and 100% of IMAX theaters. With DLP technology dominating the projector market with over 50% market share, BenQ is today the best-selling DLP projector brand offering unparalleled world-class performance
- 480i
- 480p
- 576i
- 576p
- 720p
- 1080i
- 1080p
- NTSC
- PAL
- SECAM
- Working temperature: 0 ~ 40°C
- Storage temperature: -20 ~ 60°C
- Humidity: 10 ~ 90% RH (no condensation)
- Keystone correction in two planes
- Automatic trapeze correction
- Corner Fit
- USB reader
- LAN Control
- AMX / PJ Link / Crestron / Extron IPL compatibility
- MDA LAN Display compatibility
- 4
split screen - Simultaneous work with QCast
- Power cable
- Remote control
- AAA x2 batteries
- VGA cable
- Quick start guide
- User manual on CD
- Lens cover
296 x 120 x 221 mm
